Alpha Smart Grow Cabinet

Brief Description :

PLC base controller, smart grow chamber, 210-watt grow light, all in one grow light, Growing area – 60 cm x 60 cm x 90 cm (L x W x H) Temperature, Humidity and Co2 Control & indication, with AHU (air handling unit) and dimming and spectrum control of light.

Internal size (W x D x H) cm: 60 x 60 x 90

Outer Size (W x D x H) in cm: 78 x 85 x 180

Grow chamber is suitable for all types of local plant growth. More energy efficient own it, you are ready to do research.

Call Now

Model : Alpha

Minimum Order : 1

Key Features :

▪ All in One grow light
▪ 0-100% dimming of light
▪ 0-1000 PPFD at 45 cm from light
▪ 20°C to 50°C Temperature control
▪ 40 to 85% RH.
▪ 324 litter capacity of GC
▪ 350 to 1200 PPM Co2
▪ AHU with 20% fresh air per hour

Key Benefits & Advantages :

Lighting Mastery: Set 'n' of spectrum combination using ALL IN ONE grow light.

Dynamic Lighting Control: Enjoy 0-100% dimming and 0-1000+ PPFD adjustments at 50cm, tailoring light to your plants' exact needs.

Optimal Environment: From 20°C to 50°C, fine-tune temperature and 40-85% RH for ideal growth conditions year-round.

CO2 Supercharge: Improve photosynthesis by changing the CO2 levels (350 to 1200 PPM) for faster, healthier plants.

Fresher Air, Faster Growth: An integrated AHU introduces 20% fresh air per hour, help to improve ventilation for promoting robust and rapid plant development.

Speed Breeding Success: Achieve exceptional results with simplified, effective control over light, climate, and CO2 – your formula for speed breeding triumph.

Applications :

▪ Horticultural research .
▪ Speed Breeding.
▪ Pharma Companies.

Spectrum :

Set 'n' number of spectrum option using ALL IN ONE grow light

Technical Specifications

Main System Technical Specification

Cabinet Weight (Kg)	80 Kg
Outer Dimension	Height (in./mm): 70 / 180
	Width (in./mm): 30 / 78
	Depth (in./mm): 33 / 85
Inner Dimension	Height (in./mm): 35 / 90
	Width (in./mm): 24 / 60
	Depth (in./mm): 24 / 60
Power Requirement (50Hz)	230 VAC, 3 A single phase
Cooling Requirement	20°C to 60°C

Controller Technical Specification

Control characteristic	Digital controlling
Control method	PLC control
Rated input voltage	180VAC- 240VAC
Response time	＜5sec
Working temperature	-0°C -- +45°C
Working humidity	≤85% RH
Degree of protection	IP50
