Speed Breeding Growth Chamber
Technical Specification Of Plant Growth Chamber For Speed Breeding :
1. Key Technical Specifications :
- ▪ Interior dimension 2ft×3ft×6ft (Feet) [Available in different customized sizes]
- ▪ Insulation 40 mm or 60 mm
- ▪ Insulation Density: 40 Kg/Cubic meter
- ▪ Temperature range 10° – 45° degree
- ▪ Temperature humidity range between 30% to 75 %
- ▪ Temperature uniformity: ±0° degrees
- ▪ Humidity uniformity: ± 2%RH
- ▪ Fresh Air: 10% per hour
- ▪ Co2 supply provision with cut off sensor
- ▪ Real time basis control
- ▪ Plants capacity: 700-1000 No’s (One plant)
2. Air-conditioning System :
- ▪ Regulation and control: Dual discharge evaporator coils, re-circulated air in the room by distributed uniform horizontal through back wall Plenum
- ▪ Air conditioning system including all necessary fans, heaters, and drives
- ▪ Heating: Stainless steel sheathed Heater (surface evaporating system)
- ▪ Humidifier Humidification system with the necessary fittings
- ▪ Allow Drastic
3. Lighting System :
- ▪ 0-30 v Grow Light
- ▪ Suitable for all growth stages of plants
- ▪ Make: Nexsel, Model: 3-IN-1
- ▪ Lighting On-Off control with timer
4. Cooling System :
- ▪ Single Compressor system for maintaining the temperature in chamber
- ▪ PLC/PID based Compressor/heater control is provided for precise climatic control
- ▪ Condensing unit is charged with CFC free refrigerant
- ▪ Refrigerators function monitored by controller including visual and audible alarm
5. Control System :
- ▪ Temperature sensor: Reading displayed will be average of two NTC sensors (which is more uniform and reliable)
- ▪ Humidity Sensor: Electronic capacitive humidity sensor
- ▪ Programmable PLC and Touch Screen controller
- ▪ Resolution: Temperature 0.1°, Humidity 0.1%RH
- ▪ Set range: Temperature 10° – 40°, Humidity: Ambient – 85%RH
- ▪ Audible alarms are included based on user defined limits
6. Growing System :
- ▪ Grow bed size: 5ft × 5ft × 3ft (Length x Width x Height)
- ▪ # Grow bed: 3 No’s
- ▪ Growing media: Coco peat + Soil
- ▪ Material: Aluminium
7. Security Protection System :
- ▪ Over temperature protection
- ▪ Overload protection of motor
- ▪ Overload protection of Compressor
- ▪ Fuse & MCB protection for each control and lighting circuit
- ▪ Range Mount Disconnect for Power
8. Equipment working condition :
- ▪ Ambient temperature: 5°C – 40°C, Relative humidity: ≤75%RH
- ▪ Power supply requirement: Power voltage: AC 440V±10% 50Hz, 3-phase + ground wire protection
- ▪ Power switch: AC switch Current 30A
- ▪ Water requirement for Humidity: Water flow/5Ltr, Water pressure: 0.5~3bar
9. After-sale service :
- ▪ Charge free warranty will last 1 year from the date of equipment delivery. After the warranty period, the user will be charged properly as Annual service. 2 time service
10. Technical Training :
- ▪ Provide Charge-free training to two operators for each user (In user site after installation and commissioning of the equipment)
11. Accessories :
- ▪ Warranty Certificate: one copy
- ▪ Operation & Maintenance Manual: one copy
- ▪ Circuit diagram: one copy
12. Included things :
- ▪ Machine
- ▪ Machine Installation charges
- ▪ One year service
- ▪ Internal growing structure
- ▪ Civil work
- ▪ Weight charges
13. What not included :
- ▪ Unloading of machine
- ▪ Storage condition
- ▪ Electric and water supply on site
- ▪ Water requirement: 5-8 litre per hours (Vapour particle size: 5-7 micron)
