Spectrum Selection Guide

Professional LED Grow Light Product Brouchers

Since 2015 we have been committed to creating the best LED grow lights in the market. We focus on plant biology research and finding the best possible spectra for optimal plant development. Our fixtures are made up of highest quality components, including customize LED chips that produce light spectra we have developed.

OUR MAIN FOCUS IS TO GIVE BEST POSSIBLE HORTICULTURE LIGHTING SOLUTION TO OUR CUSTOMERS.

Nexsel Spectrum:

Nexsel’s spectrum offer the best possible lights for plant in most energy efficient way. Nexsel designed spectrum for optimum plant growth in different application.

Nx1: Strong vegetative growth

Nx2: Flowering growth

Nx3: Fruiting growth

Nx4: Cool white spectrum

Nx5: Architectural application (Green wall , ornamental)

Nx6/Nx6.1: pectrum for biotech and as supplementary light

AP1: For planted aquarium

Nexsel Spectrum Selection Guide

Nexsel’s spectrum offer the best possible lights for plant in most energy efficient way. Nexsel designed spectrum for optimum plant growth in different application.

Nx1.1 – Spectrum for Strong vegetative growth

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
1	28	23	40	8	92	11919	56	1.20	5.42	1.44

NxIB – Optimized spectrum for strong vegetative growth

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0.2	33	29	29	9	92	15635	16	1.13	3.63	0.88

Nx2 – Spectrum for enhancing vernalization process, flowering and stem elongation.

Vernalization, flowering, rooting

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	11	7	65	18	83	1945	19	1.56	3.69	5.89

Nx3 – Fruiting growth – Specially designed for fruiting stage

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0.01	29	21	38	11	89	0	0	1.37	3.56	1.31

Nx4– Veg growth for hobby / Cool white spectrum

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	25	47	26	2	98	5623	81	0.53	13.05	1.07

Nx4a– Vegetative growth

Vegetative growth, tissue culture, propagation.

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	9	38	52	3	97	2748	89	0.24	16.67	5.96

Nx4B – Broad spectrum – Close to plant abortion curve well suited commercial horticulture and research applications.

ALL growth stages

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	11	33	45	11	89	3190	94	0.34	4.10	3.94

Nx6.1 – Spectrum for vegetative growth

Vegetative growth, tissue culture, propagation.

Designed and proven to quickly boost plant biomass

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	13	25	61	2	98	3896	70	0.51	31.23	4.83

Nx7 – Specially designed Strawberry application

All plant growth stages

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
2	14	20	49	15	83	2578	81	0.74	3.24	3.43

NxR – Red lettuce spectrum

Specially optimized for coloured lettuce

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
2	59	4	26	9	89	0	0	14.21	2.94	0.45

NxCMF – Cordyceps Militaris

Specially designed to increase cordycepin level

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
2	40	0.2	59	0.1	98	0	0	234.57	567.62	1.48

NxK4 –Sun-like, wide spectrum for research and biotech

Green wall, Strong vegetative growth

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	21	38	36	6	94	4966	98	0.55	6.13	1.72

Nx5 – Green wall spectrum, warm white

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0	11	40	44	6	94	3040	81	0.26	7.36	4.12

Nx123

UV	B	G	R	FR	PAR	CCT	CRI	B:G	R:FR	R:B
0.02	15	9	60	16	84	2459	7	1.62	3.75	3.93

Nexsel Spectrum Data

	Nx1	Nx1.1	Nx2	Nx3	Nx4	Nx5	NX6	Nx6.1	Nx7
UV < 400 nm	2.0%	2.0%	0%	5.0%	0.0%	0.0%	0.0%		0%
Blue 400-500 nm	12.0%	12.5%	8%	45.0%	5.0%	14.0%	6.0%		14%
Green 500-600 nm	41.0%	18.0%	4%	20.0%	82.0%	31.0%	79.0%		11%
Red 600 -700 nm	30.0%	58.5%	64%	25.0%	13.0%	43.0%	15.0%		62%
Far Red 700- 800 nm	6.0%	9.0%	24%	5.0%	0.0%	12.0%	0.0%		9%
PAR 400-700 nm	92%	89.0%	76%	90%	100%	88%	100.0%		91%
CCT (k)	N/A	N/A	N/A	N/A	6500	N/A	5000
Umol/J	2.2-2.4	2.2-2.4	2.2-2.4	2.2-2.4	2.2-2.4	2.2-2.4	2.2-2.4		2.2-2.4

Please Note – Typical values mentioned in table, there will be some variation due fixture or LED disparity.

Application

All spectra are available in all models. Through conducting more than 100+ trials we have collected data on optimal light intensities in each growth phase for most commonly cultivated plants India. We advise our customers on the spectrum and model selection for their particular application.

For more information please contact sales@nexsel.tech

Spectrum Application

	Nx1	Nx1.1	Nx2	Nx3	Nx4	Nx5	NX6	Nx6.1	Nx7
Vegetative Growth	Ο	Θ			Ο			Θ
Flowering			Θ
Fruiting				Θ
Strawberry									Θ
Tissue culture							Ο	Θ
Military Fungus							Ο	Θ
Speed Breeding					Θ
Architectural						Θ

Θ – Excellent fit, Ο – Good fit

Nx1.1

Nx1.2

Nx2

Nx3

Nx4

Nx5

Nx5.1

Nx4B

Nx6.1

Nx6.2

NxCMF

Nx123

NxR

Vegetative Growth

Flowering

Fruiting

Strawberry

Tissue culture

Military Fungus

Seed Germination

Algae

Supplementary Light

Succulent

All Growth Stages

Red Lettuce

Microgreens

Green Wall

Θ – Excellent fit, Ο – Good fit

Lighting Planning

We use our light planning technology as well as the industry standard Dialux to create light plans for our customers, free of charge. Also we guide for no. of luminaries, DLI , photoperiod, distance between two lights, light installation and all lighting related parameters.
Light plans determine an optimal number of luminaires and their optimal placements to reach customers’ goals.

Typical Model Applications

	HYGL5	HYGL8	HYGL8.1	GHGL	TSGL8	AQGL	GWGL
Vertical Farming	Θ	Θ	Θ				Θ
Tissue culture					Θ
Militry Fungus
Speed Breeding				Θ
Greenhouse	Ο	Ο		Θ

Θ – Excellent fit, Ο – Good fit

	HYGL8	HYGL8.1	GHGL-R	TSGL8/R	GHGL-S	GWGL	TL200/400	ALL IN 1	3 IN 1
Vertical Farming	Θ	Θ
Tissue culture				Θ
Algae					Θ
Military Fungus	Θ
Supplemental Lights							Θ
Speed Breeding			Θ		Θ		Θ	Θ	Θ
Vertical Wall
Microgreens	Θ
Green Wall			Ο			Θ
Research Purpose								Θ
Greenhouse			Θ		Θ

Θ – Excellent fit, Ο – Good fit
