4ft 36W LED Grow Light for Leafy Vegetables
4ft 36W LED Grow Light for Leafy Vegetables
Model : HYGL8.1 Nx1.2 (1.2 m)
Length & Wattage : 4ft | 36W
Available Spectrums : Nx1.2, Nx4
IP Rating : IP54
Warranty : 24 months
Delivery Charges : 400Rs
The Nexsel HYGL8.1 Nx1.2 (1.2 m) (4ft 36W LED Grow Light for Leafy Vegetables) is a 36 W LED grow light from Nexsel Tech Pvt. Ltd., Pune, India. It uses the Nx1.2 spectrum, is rated IP54 and measures 1200 x 30 x 35 mm, 24-month standard warranty. Orders dispatch within 7 working days and prices exclude GST.
Key Features, Benefits & Advantages
Top Features
- 36 W in a 1.2 m, 0.55 kg bar with a 120 degree beam
- Nx1.2 spectrum with 1% UV and an 80/20 diffuser
- Specially designed C3 connectors; 2-pin top input, inter-connectors and F2F
- Triac dimming optional; 100% flicker-free output optional
- PPE 2.2 to 2.4 µmol/J; 120 lm/W
- Backed with 24-month warranty
Benefits & Advantages
- Faster harvests, lower energy — Nexsel states 15% faster harvest cycles and 20% lower energy use at the same intensity (manufacturer claim).
- Twice the output of the 18 W bar — Same 30 x 35 mm section as the 18 W HYGL8 at twice the power, so one bar lights a wider tray or a taller tier.
- Less wiring per tier — Bars chain with inter-connectors or F2F connectors; Nexsel's sheet quotes up to 80% less wiring and 60-70% faster installation (manufacturer figures).
Technical Specifications
Electrical Parameters
| Input Voltage (V AC) | 220 to 240 |
| Input Power (Watts) | 36 |
| Input Current (Amps) | 0.15 |
| Frequency (Hz) | 50 |
| Light Source | SMD LED |
| THD | Less than 10% |
| Power Factor | 0.9 |
| Dimming Interface | Triac dimming (optional) |
| Surge Protection (kV) | 1 |
Mechanical Parameters
| Dimensions (L×W×H) mm | 1200 x 30 x 35 |
| Weight (kg / lb) | 0.55 / 1.21 |
| Material | Aluminium |
| Fixture Colour | White |
| Beam Angle / Light Distribution | 120° |
| Form Factor | Linear |
Performance Parameters
| PPE (µmol/J) | 2.2 to 2.4 |
| Luminous Efficacy (lm/W) | 120 |
| LED Lifespan (Hrs) | 50,000 |
| Certifications | BIS, CE, RoHS |
Environmental Parameters
| Operating Temperature (°C) | 0 to 55 |
| Operating Humidity (%) | Up to 95 |
| IP Rating | IP54 |
Spectrum Details
Photon flux distribution, measured per fixture.
| Spectrum | UV | B | G | R | FR | PAR | ePAR | CCT | CRI | B:G | R:FR | R:B |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nx1.2 | 1% | 30% | 25% | 37% | 7% | 92 | 12222K | 63 | 1.2 | 5.2 | 1.2 | |
| Nx4 | 0% | 30% | 25% | 38% | 7% | 93 | 6331K | 82 | 1.2 |
Installation, Connectivity & Options
Mounting Options
- Holding Clamps (supplied)
- Cable Tie
Connecting Options
- 2-pin Top Input
- Inter-connectors
- F2F Connectors
What it is and who it is for
The 4ft 36W HYGL8.1 is a 1.2 metre linear LED grow bar for indoor leafy production. It has the same 30 x 35 mm section as the 18 W HYGL8 but twice the power, so one bar lights a wider tray or a taller tier. Its 120 degree beam spreads light along the full 1.2 m run.
This listing is the Nx1.2 version: a blue-and-red balanced spectrum with a small 1% UV component and an 80/20 diffuser. The housing is aluminium and IP54-rated, so it tolerates the humidity of a grow room. Nexsel is a Pune-based manufacturer and ships across India.
Nx1.2 is 30% blue, 25% green, 37% red and 7% far-red, plus 1% UV (390 to 730 nm). ePAR is 92, colour temperature is 12,222 K and CRI is 63. The tall colour temperature and low CRI describe how the light looks to people; they result from a plant-tuned blue-red mix, not a defect. If you want a spectrum with no UV, Nexsel also lists Nx4 on this page - see the Spectrum Selection Guide to compare.
The Nx4 version on this page has no UV: 30% blue, 25% green, 38% red and 7% far-red, with ePAR 93, colour temperature 6,331 K and CRI 82. It uses a clear diffuser instead of the 80/20 diffuser; Nexsel states the clear diffuser raises intensity at the same wattage and that Nx4 saves 20% electricity at the same intensity (manufacturer claims). 100% flicker-free output is optional on both versions.
Who it suits:
- Hydroponic and NFT growers who want higher intensity from one bar over lettuce, spinach, kale, basil and amaranthus
- Vertical-farm and container-farm operators with taller tiers or wider trays
- Commercial leafy-green growers who want fewer fixtures per tier
- Buyers comparing the 36 W bar with the 18 W HYGL8 on the same 1.2 m length
Light intensity at the plant (PPFD)
Measured under one luminaire over a 1.2 m x 0.3 m area: peak 81 at 30 cm above the sensor (38 to 81 across the grid) and peak 53 at 45 cm (27 to 53). A higher-efficiency 2.6-3.1 PPE version peaks at 96 (30 cm) and 64 (45 cm). Values are PPFD in µmol/m²/s.
Nx1.2, 30 cm above the sensor
| Grid row | Left | Centre | Right |
|---|---|---|---|
| Row 1 | 39 | 47 | 39 |
| Row 2 | 66 | 81 | 65 |
| Row 3 | 38 | 49 | 39 |
Nx1.2, 45 cm above the sensor
| Grid row | Left | Centre | Right |
|---|---|---|---|
| Row 1 | 29 | 48 | 27 |
| Row 2 | 35 | 53 | 34 |
| Row 3 | 30 | 47 | 28 |
Nx4 under the same luminaire and area: peak 100 at 30 cm (49 to 100 across the grid) and 62 at 45 cm (36 to 62). A 2.6-3.1 PPE version peaks at 115 and 74. Nx1.2 above peaks at 81 and 53.
Nx4, 30 cm above the sensor
| Grid row | Left | Centre | Right |
|---|---|---|---|
| Row 1 | 58 | 66 | 58 |
| Row 2 | 85 | 100 | 84 |
| Row 3 | 49 | 60 | 50 |
Nx4, 45 cm above the sensor
| Grid row | Left | Centre | Right |
|---|---|---|---|
| Row 1 | 38 | 57 | 36 |
| Row 2 | 44 | 62 | 43 |
| Row 3 | 39 | 56 | 37 |
How to use these numbers: daily light integral (DLI, mol per m² per day) = PPFD x hours of light x 0.0036. Pick the PPFD your crop needs, then choose mounting height and number of fixtures to reach it. Measure intensity at canopy with a PAR meter / quantum sensor.
Installation and electrical
Mount with the supplied holding clamps or a cable tie. Power connects through a 2-pin top input; bars chain with inter-connectors or F2F connectors, which cuts wiring per tier (Nexsel's sheet quotes up to 80% less wiring and 60-70% faster installation than conventional fixtures - manufacturer figures). The sheet lists C3 connectors and optional 100% flicker-free output.
See the Hydroponics installation guide for mounting and wiring, and the HYGL8.1 model page for full model details.
Choosing the right Nexsel model
HYGL8.1 36 W is the high-output 1.2 m leafy bar. The 18 W HYGL8 page uses the same body at half the power; the 3 ft page is the shorter option. Nx1.2 carries 1% UV, Nx4 none.
- 4ft 18W Grow Light for Leafy Vegetables
- 3ft 14W Grow Light for Leafy Vegetables
- 4ft 36W Grow Light for Strawberry
Related reading: Hydroponics with LED Lights in UAE, Vegetable Production Using Indoor Hydroponics System and Lighting Control Systems for CEA.
Warranty, delivery and returns
24-month standard warranty from the date of shipment (Nexsel Warranty Policy).
Orders are dispatched within 7 working days and are delivered within 7 days of dispatch. Prices on this page exclude GST, which is added at checkout. Delivery is charged as shown at checkout.
Returns are accepted within 7 days of receipt if the product is damaged, defective or not as described.
About Nexsel
Founded in 2017, Nexsel Tech Pvt. Ltd. is a horticulture lighting manufacturer based in Pune, India, serving over 4,000 customers across 16 countries and 4 continents. With a 10,000 sq. ft. plant research facility and 120+ plant lighting recipes, Nexsel delivers research-driven lighting solutions. Need a layout? Call 98817 98822 or email [email protected].
Frequently Asked Questions
How much electricity does a 36 W grow bar use?
It draws 36 W, or 0.036 kW. Run for 16 hours a day it uses 0.576 kWh daily, about 17.3 kWh a month. Multiply that by your electricity tariff for the running cost. The 16-hour day is only an example; set your own photoperiod.
How is the 36 W bar different from the 18 W HYGL8?
Both are 1.2 m long with a 30 x 35 mm section. The 36 W bar has twice the power, draws 0.15 A against 0.075 A and weighs 0.55 kg against 0.26 kg. In Nexsel's test it reads a peak of 81 at 30 cm.
How high should I mount it above lettuce or spinach?
Nexsel measured at 30 cm and 45 cm. Under one bar the peak is 81 at 30 cm and 53 at 45 cm. Hang it closer for more intensity and raise it as plants grow. Check your crop's own light needs first.
Is IP54 enough for a humid grow room?
IP54 means the bar is protected against dust ingress and splashing water from any direction, and the data sheet lists operating humidity up to 95%. It is not submersible and should not be hosed down, so keep it clear of direct water jets.
Can I dim the bar?
Triac dimming and fully flicker-free output are listed as options on the data sheet. State the option you need when you order or contact Nexsel on 98817 98822, because they are not the default configuration.
How many 36 W bars do I need per tier?
It depends on the intensity you want. One bar at 30 cm reads 38 to 81 across a 1.2 x 0.3 m area in Nexsel's measurements. Send your tier length, width and crop to [email protected] and the team will advise a layout.
What warranty does it carry and how fast does it ship?
The standard warranty is 24 months from the date of shipment. Orders dispatch within 7 working days and arrive within 7 days of dispatch. Prices exclude GST, and returns are accepted within 7 days if the item is damaged, defective or not as described.
What is the difference between Nx1.2 and Nx4 on this bar?
Nx1.2 has 1% UV and an 80/20 diffuser; Nx4 has no UV and a clear diffuser. In Nexsel's test one bar peaks at 81 at 30 cm on Nx1.2 and 100 on Nx4. Percentages are close (blue 30%, green 25%, red 37 or 38%). Choose by crop and whether you want UV.
